R1210无源晶振,1210谐振器,美国拉隆晶振,R1210-37.400-8-F-1010-TR,进口石英晶体

频率：37.4MHz

尺寸：1.20 x 1.00mm

Part Series 型号	R1210
Original model 原厂编码	R1210-37.400-8-F-1010-TR
Product Category 产品系列	MHz晶振
Manufacturer 品牌	RALTRON晶振
Frequency 频率	37.4MHz
Load capacitance 负载电容	8pF
frequency tolerance 频率容差	±10ppm
Package Size 包装尺寸	1.20 x 1.00mm

订购热线：13380314981

R1210无源晶振,1210谐振器,美国拉隆晶振,R1210-37.400-8-F-1010-TR,进口石英晶体谐振器详细参数

Part Series 型号	R1210
Original model 原厂编码	R1210-37.400-8-F-1010-TR
Product Category 产品系列	MHz Crystal
Manufacturer 品牌	RALTRON
Frequency 频率	37.4MHz
Load capacitance 负载电容	8pF
frequency tolerance 频率容差	±10ppm
Package Size 包装尺寸	1.20 x 1.00mm
Equivalent Series Resistance 等效串联电阻	25 Ohms
Termination 脚位	4 Pad
Package Height 高度	0.35mm
Package Type 封装类型	1210-SMD
Operating Temperature 工作温度	-10℃~60℃
Packaging 包装	Tape and Reel
Mounting Style 安装方式	Surface Mount
