QTX333A10.0000B15TM,Quarztechnik贴片晶振,QTX3有源晶振
频率：10.0 MHz
尺寸：3.20mm x 2.50mm
| Original model 原厂编码 | QTX333A10.0000B15TM |
| Manufacturer 品牌 | 夸克晶振 |
| Part Series 型号 | QTX3 |
| Type 类型 | XO |
| Frequency 频率 | 10.0 MHz |
| Output Type 输出方式 | HCMOS |
| Supply Voltage 电压 | 3.3V |
| Frequency Stability 频率稳定性 | ±25ppm |
| Operating Temperature 工作温度 | -40°C ~ 85°C |
| Current Consumption 电流消耗 | - |
| Package Size 包装尺寸 | 3225石英晶振 |
订购热线：13380314981
QTX333A10.0000B15TM,Quarztechnik贴片晶振,QTX3有源晶振 详细参数
| Original model 原厂编码 | QTX333A10.0000B15TM |
| Manufacturer 品牌 | 夸克晶振 |
| Part Series 型号 | QTX3 |
| Type 类型 | XO |
| Frequency 频率 | 10.0 MHz |
| Output Type 输出方式 | HCMOS |
| Supply Voltage 电压 | 3.3V |
| Frequency Stability 频率稳定性 | ±25ppm |
| Operating Temperature 工作温度 | -40°C ~ 85°C |
| Current Consumption 电流消耗 | - |
| Package Size 包装尺寸 | 3.20mm x 2.50mm |
| Package Height 厚度 | 1.20mm |
| Termination 脚位 | 4 Pad |
| Package Type 封装类型 | 4-SMD |
| Lead Free 无铅 | Yes |
| Mounting Style 安装方式 | Surface Mount |
| Packaging 包装 | Tape and Reel |
QTX333A10.0000B15TM,Quarztechnik贴片晶振,QTX3有源晶振 相关产品
| Quarztechnik夸克晶振 | 8.0 MHz | 18 pF | ±10ppm | ±20ppm | -40 - +85°C | QTC7A8.00000FDT1I20M |
| Quarztechnik夸克晶振 | 10.0 MHz | 18 pF | ±10ppm | ±20ppm | -40 - +85°C | QTC7A10.0000FDT1I20M |
| Quarztechnik夸克晶振 | 11.0592 MHz | 18 pF | ±10ppm | ±20ppm | -40 - +85°C | QTC7A11.0592FDT1I20M |
| Quarztechnik夸克晶振 | 12.0 MHz | 18 pF | ±10ppm | ±20ppm | -40 - +85°C | QTC7A12.0000FDT1I20M |
| Quarztechnik夸克晶振 | 14.31818 MHz | 18 pF | ±10ppm | ±20ppm | -40 - +85°C | QTC7A14.31818FDT1I20M |
| Quarztechnik夸克晶振 | 14.7456 MHz | 18 pF | ±10ppm | ±20ppm | -40 - +85°C | QTC7A14.7456FDT1I20M |
| Quarztechnik夸克晶振 | 16.0 MHz | 18 pF | ±10ppm | ±20ppm | -40 - +85°C | QTC7A16.0000FDT1I20M |
| Quarztechnik夸克晶振 | 19.6608 MHz | 18 pF | ±10ppm | ±20ppm | -40 - +85°C | QTC7A19.6608FDT1I20M |
| Quarztechnik夸克晶振 | 24.0 MHz | 18 pF | ±10ppm | ±20ppm | -40 - +85°C | QTC7A24.0000FDT1I20M |
| Quarztechnik夸克晶振 | 25.0 MHz | 18 pF | ±10ppm | ±20ppm | -40 - +85°C | QTC7A25.0000FDT1I20M |
| Quarztechnik夸克晶振 | 27.0 MHz | 18 pF | ±10ppm | ±20ppm | -40 - +85°C | QTC7A27.0000FDT1I20M |
| Quarztechnik夸克晶振 | 32.0 MHz | 18 pF | ±10ppm | ±20ppm | -40 - +85°C | QTC7A32.0000FDT1I20M |
| Quarztechnik夸克晶振 | 8.0 MHz | 18 pF | ±10ppm | ±20ppm | -40 - +85°C | QTC6A8.00000FDT1I20M |
| Quarztechnik夸克晶振 | 11.0592 MHz | 18 pF | ±10ppm | ±20ppm | -40 - +85°C | QTC6A11.0592FDT1I20M |
| Quarztechnik夸克晶振 | 12.0 MHz | 18 pF | ±10ppm | ±20ppm | -40 - +85°C | QTC6A12.0000FDT1I20M |
| Quarztechnik夸克晶振 | 14.7456 MHz | 18 pF | ±10ppm | ±20ppm | -40 - +85°C | QTC6A14.7456FDT1I20M |
| Quarztechnik夸克晶振 | 16.0 MHz | 18 pF | ±10ppm | ±20ppm | -40 - +85°C | QTC6A16.0000FDT1I20M |
| Quarztechnik夸克晶振 | 20.0 MHz | 18 pF | ±10ppm | ±20ppm | -40 - +85°C | QTC6A20.0000FDT1I20M |
| Quarztechnik夸克晶振 | 24.0 MHz | 18 pF | ±10ppm | ±20ppm | -40 - +85°C | QTC6A24.0000FDT1I20M |
| Quarztechnik夸克晶振 | 25.0 MHz | 18 pF | ±10ppm | ±20ppm | -40 - +85°C | QTC6A25.0000FDT1I20M |
| Quarztechnik夸克晶振 | 27.0 MHz | 18 pF | ±10ppm | ±20ppm | -40 - +85°C | QTC6A27.0000FDT1I20M |
| Quarztechnik夸克晶振 | 32.0 MHz | 18 pF | ±10ppm | ±20ppm | -40 - +85°C | QTC6A32.0000FDT1I20M |
| Quarztechnik夸克晶振 | 8.0 MHz | 18 pF | ±10ppm | ±20ppm | -40 - +85°C | QTC5A8.00000FDT1I20M |
| Quarztechnik夸克晶振 | 12.0 MHz | 18 pF | ±10ppm | ±20ppm | -40 - +85°C | QTC5A12.0000FDT1I20M |
| Quarztechnik夸克晶振 | 12.288 MHz | 18 pF | ±10ppm | ±20ppm | -40 - +85°C | QTC5A12.2880FDT1I20M |
| Quarztechnik夸克晶振 | 15.360 MHz | 18 pF | ±10ppm | ±20ppm | -40 - +85°C | QTC5A15.3600FDT1I20M |
| Quarztechnik夸克晶振 | 16.0 MHz | 18 pF | ±10ppm | ±20ppm | -40 - +85°C | QTC5A16.0000FDT1I20M |
| Quarztechnik夸克晶振 | 18.432 MHz | 18 pF | ±10ppm | ±20ppm | -40 - +85°C | QTC5A18.4320FDT1I20M |
| Quarztechnik夸克晶振 | 20.0 MHz | 18 pF | ±10ppm | ±20ppm | -40 - +85°C | QTC5A20.0000FDT1I20M |
| Quarztechnik夸克晶振 | 24.576 MHz | 18 pF | ±10ppm | ±20ppm | -40 - +85°C | QTC5A24.5760FDT1I20M |
| Quarztechnik夸克晶振 | 25.0 MHz | 18 pF | ±10ppm | ±20ppm | -40 - +85°C | QTC5A25.0000FDT1I20M |
| Quarztechnik夸克晶振 | 27.0 MHz | 18 pF | ±10ppm | ±20ppm | -40 - +85°C | QTC5A27.0000FDT1I20M |
| Quarztechnik夸克晶振 | 30.0 MHz | 18 pF | ±10ppm | ±20ppm | -40 - +85°C | QTC5A30.0000FDT1I20M |
| Quarztechnik夸克晶振 | 40.0 MHz | 18 pF | ±10ppm | ±20ppm | -40 - +85°C | QTC5A40.0000FDT1I20M |
| Quarztechnik夸克晶振 | 48.0 MHz | 18 pF | ±10ppm | ±20ppm | -40 - +85°C | QTC5A48.0000FDT1I20M |
| Quarztechnik夸克晶振 | 16.0 MHz | 18 pF | ±10ppm | ±20ppm | -40 - +85°C | QTC3216.0000FDT1I20M |
| Quarztechnik夸克晶振 | 18.432 MHz | 18 pF | ±10ppm | ±20ppm | -40 - +85°C | QTC3218.4320FDT1I20M |
| Quarztechnik夸克晶振 | 20.0 MHz | 18 pF | ±10ppm | ±20ppm | -40 - +85°C | QTC3220.0000FDT1I20M |
| Quarztechnik夸克晶振 | 24.0 MHz | 18 pF | ±10ppm | ±20ppm | -40 - +85°C | QTC3224.0000FDT1I20M |
| Quarztechnik夸克晶振 | 25.0 MHz | 18 pF | ±10ppm | ±20ppm | -40 - +85°C | QTC3225.0000FDT1I20M |
| Quarztechnik夸克晶振 | 27.0 MHz | 18 pF | ±10ppm | ±20ppm | -40 - +85°C | QTC3227.0000FDT1I20M |
| Quarztechnik夸克晶振 | 14.7456 MHz | HCMOS | 3.3V | -40 - +85℃ | ±25ppm | QTX733A14.7456B15M |
| Quarztechnik夸克晶振 | 16.0 MHz | HCMOS | 3.3V | -40 - +85℃ | ±25ppm | QTX733A16.0000B15M |
| Quarztechnik夸克晶振 | 16.384 MHz | HCMOS | 3.3V | -40 - +85℃ | ±25ppm | QTX733A16.3840B15M |
| Quarztechnik夸克晶振 | 20.0 MHz | HCMOS | 3.3V | -40 - +85℃ | ±25ppm | QTX733A20.0000B15M |
| Quarztechnik夸克晶振 | 24.576 MHz | HCMOS | 3.3V | -40 - +85℃ | ±25ppm | QTX733A24.5760B15M |
| Quarztechnik夸克晶振 | 25.0 MHz | HCMOS | 3.3V | -40 - +85℃ | ±25ppm | QTX733A25.0000B15M |
| Quarztechnik夸克晶振 | 27.0 MHz | HCMOS | 3.3V | -40 - +85℃ | ±25ppm | QTX733A27.0000B15M |
| Quarztechnik夸克晶振 | 30.0 MHz | HCMOS | 3.3V | -40 - +85℃ | ±25ppm | QTX733A30.0000B15M |
| Quarztechnik夸克晶振 | 32.0 MHz | HCMOS | 3.3V | -40 - +85℃ | ±25ppm | QTX733A32.0000B15M |
| Quarztechnik夸克晶振 | 3.6864 MHz | HCMOS | 3.3V | -40 - +85℃ | ±25ppm | QTX533A3.68640B15M |
| Quarztechnik夸克晶振 | 4.0 MHz | HCMOS | 3.3V | -40 - +85℃ | ±25ppm | QTX533A4.00000B15M |
| Quarztechnik夸克晶振 | 7.3728 MHz | HCMOS | 3.3V | -40 - +85℃ | ±25ppm | QTX533A7.37280B15M |
| Quarztechnik夸克晶振 | 8.0 MHz | HCMOS | 3.3V | -40 - +85℃ | ±25ppm | QTX533A8.00000B15M |
| Quarztechnik夸克晶振 | 10.0 MHz | HCMOS | 3.3V | -40 - +85℃ | ±25ppm | QTX533A10.0000B15M |
| Quarztechnik夸克晶振 | 11.0592 MHz | HCMOS | 3.3V | -40 - +85℃ | ±25ppm | QTX533A11.0592B15M |
| Quarztechnik夸克晶振 | 12.0 MHz | HCMOS | 3.3V | -40 - +85℃ | ±25ppm | QTX533A12.0000B15M |
| Quarztechnik夸克晶振 | 16.0 MHz | HCMOS | 3.3V | -40 - +85℃ | ±25ppm | QTX533A16.0000B15M |
| Quarztechnik夸克晶振 | 16.384 MHz | HCMOS | 3.3V | -40 - +85℃ | ±25ppm | QTX533A16.3840B15M |
| Quarztechnik夸克晶振 | 20.0 MHz | HCMOS | 3.3V | -40 - +85℃ | ±25ppm | QTX533A20.0000B15M |
