XRCPB26M000F2P00R0,XRCFD贴片晶振,Murata村田无源晶振

当前位置：首页 » 日产进口晶振 » MuRata晶振 » XRCPB26M000F2P00R0,XRCFD贴片晶振,Murata村田无源晶振

prevnext

XRCPB26M000F2P00R0,XRCFD贴片晶振,Murata村田无源晶振

频率：26 MHz

尺寸：2.00mm x 1.60mm

原厂型号 Original model ：	XRCPB26M000F2P00R0
品牌 brand ：	Murata村田无源晶振
型号名称 Model name：	XRCPB
Type 系列：	MHz Crystal
频率 frequency ：	26 MHz
Frequency Stability频率稳定度	±20ppm
frequency tolerance频率容差	±20ppm
Load capacitance 负载电容	6pF
Size / Dimension 尺寸	2016mm晶振

订购热线：13380314981

XRCPB26M000F2P00R0,XRCFD贴片晶振,Murata村田无源晶振详细参数

原厂型号 Original model ：	XRCPB26M000F2P00R0
品牌 brand ：	Murata村田无源晶振
型号名称 Model name：	XRCPB
Type 系列：	MHz Crystal
频率 frequency ：	26 MHz
Frequency Stability频率稳定度	±20ppm
frequency tolerance频率容差	±20ppm
Load capacitance 负载电容	6pF
Size / Dimension 尺寸	2.00mm x 1.60mm
Package Height 厚度	0.50mm
ESR (Equivalent Series Resistance)ESR（等效串联电阻）	150 Ohms
Operating Temperature 工作温度	-30°C~85°C
Termination 脚位	4 pad
Package Type 封装类型	4-SMD
Packaging 包装	Tape and Reel
Mounting Style 安装方式	Surface Mount

XRCPB26M000F2P00R0,XRCFD贴片晶振,Murata村田无源晶振相关产品

XRCPB26M000F2P00R0	Murata村田无源晶振	XRCPB	MHz Crystal	26 MHz	±20ppm	±20ppm	6pF
XRCGB32M000F1H18R0	Murata村田无源晶振	XRCFD	MHz Crystal	32 MHz	±15ppm	±10ppm	9pF
XRCGB26M000F1H89R0	Murata村田无源晶振	XRCGB	MHz Crystal	26 MHz	±10ppm	±10ppm	5pF
XRCGE24M545FBA1BR0	Murata村田无源晶振	XRCGE	MHz Crystal	24.545452 MHz	±35ppm	±15ppm	8pF
XRCGB40M000F0Z00R0	Murata村田无源晶振	XRCGB	MHz Crystal	40 MHz	±100ppm	±100ppm	6pF
XRCGB38M400F1S1CR0	Murata村田无源晶振	XRCGB	MHz Crystal	38.4 MHz	±10ppm	±10ppm	10pF
XRCGB24M000F1SBAR0	Murata村田无源晶振	XRCGB	MHz Crystal	24 MHz	±20ppm	±10ppm	6pF
XRCGE30M000F3A1AR0	Murata村田无源晶振	XRCGE	MHz Crystal	30 MHz	±45ppm	±30ppm	6pF
XRCGE30M000F3A1BR0	Murata村田无源晶振	XRCGE	MHz Crystal	30 MHz	±45ppm	±30ppm	8pF
XRCGE50M000F3A1BR0	Murata村田无源晶振	XRCGE	MHz Crystal	50 MHz	±45ppm	±30ppm	8pF
XRCGB38M400F1S2FR0	Murata村田无源晶振	XRCGB	MHz Crystal	38.4 MHz	±20ppm	±10ppm	6pF
XRCGB32M000F5N10R0	Murata村田无源晶振	XRCGB	MHz Crystal	32 MHz	±30ppm	±50ppm	6pF
XRCGB25M000FAN00R0	Murata村田无源晶振	XRCGB	MHz Crystal	25 MHz	±25ppm	±25ppm	6pF
XRCGB25M000FAM10R0	Murata村田无源晶振	-	MHz Crystal	25 MHz	±40ppm	±25ppm	8pF
XRCGB25M000F0L00R0	Murata村田无源晶振	XRCGB	MHz Crystal	25 MHz	±50ppm	±100ppm	6pF
XRCGB40M000F4M00R0	Murata村田无源晶振	XRCGB	MHz Crystal	40 MHz	±40ppm	±45ppm	6pF
XRCGB24M576F0L00R0	Murata村田无源晶振	-	MHz Crystal	24.576 MHz	±50ppm	±100ppm	6pF
XRCGB27M000FAN16R0	Murata村田无源晶振	XRCGB	MHz Crystal	27 MHz	±25ppm	±25ppm	12pF
XRCGB40M000F4M02R0	Murata村田无源晶振	-	MHz Crystal	40 MHz	±40ppm	±45ppm	10pF
XRCGB26M000F0L00R0	Murata村田无源晶振	XRCGB	MHz Crystal	26 MHz	±50ppm	±100ppm	6pF
XRCGB40M000F4M01R0	Murata村田无源晶振	-	MHz Crystal	40 MHz	±40ppm	±45ppm	8pF
XRCGB27M120F2P11R0	Murata村田无源晶振	XRCGB	MHz Crystal	27.12 MHz	±20ppm	±20ppm	6pF
XRCGB32M000F2P10R0	Murata村田无源晶振	XRCGB	MHz Crystal	32 MHz	±20ppm	±20ppm	6pF
XRCGB24M000F2P02R0	Murata村田无源晶振	-	MHz Crystal	24 MHz	±20ppm	±20ppm	10pF
XRCGB30M000F3M00R0	Murata村田无源晶振	XRCGB	MHz Crystal	30 MHz	±40ppm	±30ppm	6pF
XRCGB32M000F3N00R0	Murata村田无源晶振	XRCGB	MHz Crystal	32 MHz	±25ppm	±30ppm	6pF
XRCGB27M120F3M16R0	Murata村田无源晶振	-	MHz Crystal	27.12 MHz	±40ppm	±30ppm	6pF
XRCGB24M000F3M26R0	Murata村田无源晶振	XRCGB	MHz Crystal	24 MHz	±40ppm	±30ppm	6pF
XRCGB27M120F2P10R0	Murata村田无源晶振	-	MHz Crystal	27.12 MHz	±20ppm	±20ppm	10pF
XRCGB32M000F2P29R0	Murata村田无源晶振	-	MHz Crystal	32 MHz	±20ppm	±20ppm	6pF
XRCGB32M000F3M01R0	Murata村田无源晶振	XRCGB	MHz Crystal	32 MHz	±40ppm	±30ppm	8pF
XRCGB25M000F3N00R0	Murata村田无源晶振	XRCGB	MHz Crystal	25 MHz	±30ppm	±30ppm	6pF
XRCGB32M000F2N13R0	Murata村田无源晶振	-	MHz Crystal	32 MHz	±30ppm	±20ppm	10pF
XRCGB26M000F2P01R0	Murata村田无源晶振	-	MHz Crystal	26 MHz	±20ppm	±20ppm	8pF
XRCGB24M000F3M19R0	Murata村田无源晶振	-	MHz Crystal	24 MHz	±40ppm	±30ppm	6pF
XRCGB27M000F3M00R0	Murata村田无源晶振	XRCGB	MHz Crystal	27 MHz	±40ppm	±30ppm	6pF
XRCGB38M400F2P00R0	Murata村田无源晶振	-	MHz Crystal	38.4 MHz	±20ppm	±20ppm	6pF
XRCGB27M120F2P01R0	Murata村田无源晶振	-	MHz Crystal	27.12 MHz	±20ppm	±20ppm	8pF
XRCGB40M000F1S1BR0	Murata村田无源晶振	XRCGB	MHz Crystal	40 MHz	±10ppm	±10ppm	8pF
XRCHA16M000F0A01R0	Murata村田无源晶振	XRCHA	MHz Crystal	16 MHz	±100ppm	±100ppm	8pF
XRCGB16M000FXN16R0	Murata村田无源晶振	-	MHz Crystal	16 MHz	±40ppm	±40ppm	8pF
XRCGB16M000FXN02R0	Murata村田无源晶振	-	MHz Crystal	16 MHz	±40ppm	±40ppm	10pF
XRCGB24M000F2C01R0	Murata村田无源晶振	XRCGB	MHz Crystal	24 MHz	±50ppm	±20ppm	8pF
XRCGB16M000FXN20R0	Murata村田无源晶振	-	MHz Crystal	16 MHz	±40ppm	±40ppm	8pF
XRCGB24M000F2C00R0	Murata村田无源晶振	XRCGB	MHz Crystal	24 MHz	±50ppm	±20ppm	6pF
XRCGB24M305F3A12R0	Murata村田无源晶振	XRCGB	MHz Crystal	24.305 MHz	±35ppm	±30ppm	7.5pF
XRCGB32M000F1H2BR0	Murata村田无源晶振	XRCGB	MHz Crystal	32 MHz	±15ppm	±10ppm	10pF
XRCGB25M000F1H01R0	Murata村田无源晶振	-	MHz Crystal	25 MHz	±10ppm	±10ppm	8pF
XRCGB24M000F1H23R0	Murata村田无源晶振	-	MHz Crystal	24 MHz	±25ppm	±10ppm	6pF
XRCGB25M000F3A1AR0	Murata村田无源晶振	XRCGB	MHz Crystal	25 MHz	±35ppm	±30ppm	6pF
XRCGB25M000F3A16R0	Murata村田无源晶振	XRCGB	MHz Crystal	25 MHz	±35ppm	±30ppm	10pF
XRCTD32M000N1P1AR0	Murata村田无源晶振	XRCTD	MHz Crystal	32 MHz	±20ppm	±10ppm	6pF
XRCGE26M000FBA2AR0	Murata村田无源晶振	XRCFD	MHz Crystal	26 MHz	±35ppm	±15ppm	8pF
XRCGE24M000FBA1BR0	Murata村田无源晶振	XRCGE	MHz Crystal	24 MHz	±35ppm	±15ppm	8pF
XRCGB40M000F5A12R0	Murata村田无源晶振	XRCGB	MHz Crystal	40 MHz	±65ppm	±50ppm	6pF
XRCMD48M000F1P2AR0	Murata村田无源晶振	XRCFD	MHz Crystal	48 MHz	±20ppm	±10ppm	7pF
XRCGE25M000FBA1BR0	Murata村田无源晶振	XRCGE	MHz Crystal	25 MHz	±35ppm	±15ppm	8pF
XRCGE40M000F3A1BR0	Murata村田无源晶振	XRCGE	MHz Crystal	40 MHz	±45ppm	±30ppm	8pF
XRCGE27M000F2A1AR0	Murata村田无源晶振	XRCGE	MHz Crystal	27 MHz	±35ppm	±20ppm	6pF
XRCGE50M000F5A2AR0	Murata村田无源晶振	XRCGE	MHz Crystal	50 MHz	±50ppm	±50ppm	4.7pF
